Product Details
Boasting some impressive features: the ZJ Longarm Kit is a comprehensive package including everything needed for a great suspension lift while maintaining the vehicles crucial center of gravity. The kit includes adjustable high-clearance X-Flex upper and lower control arms with Clevite bushings and features rebuildable X-Flex joints. This lift kit features high-clearance components with a front y-link and rear 4-link control arm design. This promotes extreme axle flex while keeping pinion angles optimized. Our new forged adjustable track bar is also included in this kit!
Rough Countrys 4-inch X-Series Long Arm Suspension Lift System - 90222
Jeep: 93-98 Grand Cherokee ZJ 4WD/2WD
Part Number: RC-90222
Includes:
FRONT: Lifted coil springs
Adjustable upper control arms
Adjustable lower control arms
Crossmember
Transfer case skid plate
Sway-bar quick disconnects
Forged Adjustable track bar
Track bar bracket
3" Bumpstops
Hardware
REAR: Lifted coil springs
Adjustable upper control arms
Adjustable lower control arms
Long arm frame brackets
Track bar bracket
Bumpstop brackets
Brake line brackets
Hardware
SHOCKS: (4) Premium N3 Series
Benefits:
Aggressive appearance
Increased ground clearance
HD 0.25" thick crossmember
Lower control arms feature high clearance design
Front adjustable track bar is made of forged solid steel for unsurpassed strength and durability
Extreme travel long arms keep optimum alignment and give optimum articulation.
X-Flex control arm features:
Clevite brand OEM style rubber bushings.
Flex joints feature a massive 2.5" diameter body and 1.25" thread.
Fully greasable.
Upper joints pivot up to 20 degrees.
Lower joints pivot up to 35 degrees.
Specifics:
SKU: 90222
Install Time:8-9 hours
Notes:
Does NOT fit AWD models.
Transfer case skid plate will NOT fit models equipped with 249 transfer case.
Exhaust will have to be cut and rerouted to make sure it is away from the moving components.
Models equipped with a CV style front driveshaft may result in driveshaft vibration. If this occurs, replacing the driveshaft, axle yoke and / or transfer case yoke will need to be performed to rid the vehicle of driveline vibration. CV Driveshaft Example
